AS 63 2T ES

Kategorije

Modern Allmäher for slopes and difficult terrain

Mulch where others hit their limits. The AS 63 2T ES is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling mowing on inclines of 40 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque provides full power in high, wet grass while a third crankshaft bearing and friction discs on the wing blade protect the engine in the event of striking an obstacle. Large inflatable tyres with field studs offer ideal propulsion at speeds up to 4.0 km/h.
The drive-reduction transmission with a gear ratio of 1:13.44 allows the AS 63 2T ES to brake autonomously when moving downhill. The machine will not speed up when moving downhill, no matter how steep the incline. When in drive the AS 63 2T ES has a permanently locked limited slip differential which increases traction and safety, particularly on slopes.
Work rates reaching 2,400 m² per hour are possible due to a high-performance 2-stroke engine with up to 6.7 hp, variable drive and a 61 cm cutting width. The AS 63 2T ES easily cuts grass up to 100 cm high.

Simple, convenient and safe operation

The AS 63 2T ES works with operating levers that activate the parking brake, the traction drive, the limited slip differential and the blade clutch. Absolute safety for slope mowing is achieved by an automatic parking brake and limited slip differential which remains permanently locked while the machine is in drive. When the drive lever is released, the parking brake automatically engages and the AS 63 2T ES stops, whether on a slope or level ground. For convenient operation the guide bar is equipped with a V-handlebar which can be adjusted laterally and for height without tools. “VibrationProtect” vibration damping reduces hand-arm vibration to a minimum.

Product advantages

Engine suitable for slopes

The world's only AS 2-stroke engine with EasyStart has position-independent lubrication, ensuring safe operation even on steep slopes.

Mow and mulch in one step

The cross-blade system of this Allmäher easily cuts and shreds high growth with an impressive cutting performance and excellent mulching result.

Automatic parking brake

When the drive lever is released the machine stops automatically, whether on a slope or level ground.

Self-braking traction drive

The drive-reduction transmission with a 1:13.44 gear ratio delivers optimal propulsion and brakes autonomously when moving downhill.

Special feature: automatic locking differential

Only when the drive wheel is spinning, the differential lock activates automatically. Otherwise, it is inactive and the machine is freely controllable.

High cutting capacity

1:1.6 engine-blade reduction for high cutting capacity in dense growth.

Engine protection

Separate engine and blade shaft protects engine.

Conical mower deck

Conical mower deck generates an airflow that uniformly whirls the cuttings in the mulching unit, delivering excellent cutting results.

Detalji o proizvodu

product-image

Varijator

Regulator brzine omogućava varijabilno podešavanje brzine pogona.

product-image

Prigušenje vibracija

"VibrationProtect" smanjuje vibracije na ruke na minimum.

product-image

Jednostavan transport

AS 63 se može lako presaviti za kompaktne dimenzije transporta.

product-image

Položaj za čišćenje i servisiranje

Kompaktni dizajn AS 63 omogućava lako i praktično čišćenje.

Pribor

product-image

Uređaj za plašenje kukaca

AS-Motor uređaj za plašenje kukaca je inovativna priložba za košenje koja štiti oprašivače i malu divljač. Znanstveno testiran kako bi povećao stopu bijega kukaca, osigurava održivo košenje uz održavanje učinkovitosti. Dizajniran za izdržljivost, prilagodljivost i laku integraciju s profesionalnim kosačicama AS-Motor.

» nastavi čitati
product-image

Radni satnik

Dokumentacija radnih sati.

product-image

Set za mulčiranje AS 62, AS 63

Za još finije usitnjavanje i ujednačenije rezultate kosidbe na travnjacima s travom visine do 40 cm.

product-image

Dvostruke gume AS 63

Opcionalne dvostruke gume za poboljšanu vuču na kosinama s brzim zaključavanjem.

product-image

Nagibomjer

Pregledna prikaza nagiba.

product-image

Filter za usisavanje zraka

Visoko postavljeni filter za usisavanje opskrbljuje motor čistim zrakom.

product-image

Sintetično ulje za 2-taktne motore "Titan 2T", 1-litra

Premijsko ulje za 2-taktne motore s optimalnim omjerom miješanja prijateljskim prema okolišu. Preporučuje se za sve AS 2-taktne motore. Testirano i odobreno za naš preporučeni omjer miješanja 1:100. Također pogodno za omjer miješanja 1:50. Zamjenjuje naše bivše ulje TITAN 2T 100S, koje više nije dostupno.
